With huge range, robust components and grippy mixed-surface tires, the sporty Cannondale Tesoro Neo X electric bike is built to get you to it all week, and away from it all on the weekend.
- SmartForm C2 alloy frame
- Bump-smoothing suspension fork provides 63 mm of travel
- Bosch Smart System Performance Line Sport 28 mph drive unit; 500 Wh battery provides a range of up to 70 miles
- Battery is removable; no tools required for removal
- microSHIFT Marvo 9-speed shifting
- Riderever hydraulic disc brakes
- Integrated headtube running light; Axa Compactline 35E front light; Axa Blueline rear light
- Tubus rear rack (25 kg, Racktime compatible)
- Full-coverage fenders
- NOTE: Specs and images are subject to change based on component availability
Imported.
- 1 year of free adjustments (see more below)
- In-store bike assembly
- Pickup in store or curbside
- Bike experts available at 170+ bike shops
- An additional year of free adjustments on e-bikes
- 20% off shop services
- Free tubes with purchase of flat tire repair (Co-op Cycles brand tubes only; tube must be installed at time of purchase)
New bikes go through a normal break-in period, after which they should be readjusted. All electric bicycles sold at REI include free adjustments for the defined period (one year after purchase date for non-members, or two years for REI Co-op Members)—as many times as you need. Included: derailleur and brake adjustments, lateral wheel truing, hub and headset bearing adjustments, tire inflation, chain lubrication and e-bike firmware updates. Not included: replacement or installation of new components or accessories, any other services. Call your local REI Co-op Bike Shop for more information.
UL2849 certified
| Best Use | Urban Cycling |
|---|---|
| E-Bike Classification | Class 3: pedal assist up to 28 mph |
| Motor | Bosch Performance Line Sport, Smart System |
| Motor Type | Mid-Drive |
| Motor Torque (Nm) | 65 Newton meters |
| Battery Type | Lithium Ion |
| Battery Capacity (Wh) | 500 watt hours |
| Battery Removable | Yes |
| Charge Time (hrs) | 4 hours |
| Pedal Assist Range | 70 miles |
| Frame | SmartForm C2 alloy, removable 500 Wh downtube battery, integrated front running light, tapered headtube, internal cable routing, 135 mm QR hub spacing, IS disc mount, motor protection |
| Bike Suspension | Front Suspension |
| Fork | SR Suntour Mobie A32, 63 mm travel, coil with preload adjuster, lockout, crown light mount, 44 mm offset |
| Fork Travel | 63 millimeters |
| Crankset | FSA for Bosch |
| Shifters | microSHIFT Marvo XPress M859, trigger style, 9-speed |
| Rear Derailleur | microSHIFT Marvo, 9-speed |
| Rear Cogs | microSHIFT H-Series, 11-36T, 9-speed |
| Number of Gears | 9 gear(s) |
| Brake Type | Hydraulic Disc Brake |
| Brakes | Riderever Attack-U-OE, 2-piston hydraulic disc, 180/180 rotors |
| Brake Levers | Riderever Attack-U-OE |
| Rims | Alloy, double wall, 32 hole, 25 mm internal width, disc-specific |
| Front Hub | Shimano MT400B, 110 x 15 mm thru axle |
| Rear Hub | Shimano UR600, 135 mm quick-release |
| Wheel Size | S: 27.5 inches M: 29 inches L: 29 inches XL: 29 inches |
| Tires | Continental Race King: 27.5 x 2.20 in. 55-584 (S); 29 x 2.20 in. 55-622 (M-XL) |
| Tire Width | 2.2 inches |
| Handlebar Shape | Riser Bar |
| Handlebar | Cannondale 3 Riser, 6061 alloy, 15 mm rise, 8 deg. sweep, 4 deg. rise, 740 mm |
| Stem | Cannondale 3 with Intellimount, Alloy, 31.8 mm clamp |
| Seat Post | Cannondale 4, 6061 alloy, 31.6 mm |
| Saddle | Selle Royal Vivo Active Ergo with reflective accents |
| Pedals | Cannondale Fitness |
| Headset | Semi-Integrated, Tapered; 1-1/8 to 1-1/2 in. |
| Chain | KMC Z9, 9-speed |
| Weight | Unavailable |
| Gender | Unisex |
| S | M | L | XL | |
|---|---|---|---|---|
| Height Range | 5'4" - 5'8" | 5'7" - 6'0" | 6'0" - 6'3" | 6'4" - 6'8" |
| Reach | 39.3 | 43 | 45.1 | 47.4 |
| Stack | 62.9 | 62.9 | 63.7 | 64.4 |
| Effective Top Tube | 58.0 | 61.7 | 64.0 | 66.5 |
| Seat Tube Center-Top | 38.0 | 43.5 | 48.5 | 53.5 |
| Standover Height | 74.6 | 77.5 | 81.3 | 84.7 |
| Head Tube Length | 12.8 | 12.8 | 13.6 | 14.4 |
| Head Tube Angle (degrees) | 68.0 | 68.0 | 68.0 | 68.0 |
| Seat Tube Angle (degrees) | 73.5 | 73.5 | 73.5 | 73.5 |
| Bottom Bracket Height | 31.5 | 31.5 | 31.5 | 31.5 |
| Wheelbase | 115.5 | 119.2 | 121.6 | 124.2 |
| Chainstay | 47.9 | 47.9 | 47.9 | 47.9 |
| Fork Offset | 5.1 | 5.1 | 5.1 | 5.1 |
Sizing Notes
Measurements are stated in centimeters unless otherwise indicated.
How we measure bikes
- Standover Height Standover Height is a measurement from the ground to the top of the top tube, measured at the midpoint of the top tube.
- Reach Reach is the horizontal distance from the center of the cranks to the center of the head tube, measured at head tube level.
- Stack Stack is the vertical distance from the center of the cranks to the center of the head tube, measured to the top of the head tube.
- Effective Top Tube Effective top tube is the distance from the center of the head tube to the center of the seat tube/seat post, measured parallel to the ground.
- Seat Tube Center to Top Seat Tube length is the measurement of the seat tube, from the center of the cranks to the top of the seat tube.
- Head Tube Length Head Tube Length is measured from the bottom to the top of the head tube.
- Head Tube Angle Head Tube Angle is the acute angle between the head tube and the ground (measured towards the rear of the bike)
- Seat Tube Angle Seat Tube Angle is the acute angle between the seat tube and the ground (measured towards the rear of the bike).
- Bottom Bracket Height Bottom Bracket Height is a measurement taken vertically from the ground up to the center of the cranks.
- Wheelbase Wheelbase is the measurement from the center of the front axle to the center of the rear axle.
- Chainstay Length Chainstay Length is the measurement from the center of the cranks to the center of the rear axle.
- Fork Offset Fork Offset, or rake, is the distance from the front axle to a line drawn parallel to the center of the head tube or steering axis.
