With geometry that's at home on backcountry rides and buffed-out flow trails, the Salsa Moraine 145 CUES 10 electric mountain bike makes sessioning lines and taking another lap feel like a breeze.
- Adds range, route options and capability to every trail ride
- 6061-T6 aluminum frame
- 145 mm of Split Pivot suspension to maximize traction and efficiency
- Split Pivot and frame design philosophy allows riders to swap between travel classes
- Fazua Ride 60 Class 1 mid-drive motor (20 mph/32 kph max assist)
- 60 Nm max torque
- 430 Wh Fazua Energy 430 internal battery
- Compatible with 210 Wh Fazua Energy range-extender battery (not included)
- Fazua LED Hub on top tube for battery status and riding modes
- Fazua Ring Control for easy ride mode selection
- Internal cable and hose routing
- 12 x 148 mm Boost rear spacing
- SRAM UDH compatible
- Accommodates wheels and tires up to 29 x 2.6 in. or 27.5 x 2.8 in. (spec'd with a 29 in. wheels with a 2.6 in. tire in front and 2.5 in. tire in back)
- Integrated tool and tube strap location in front triangle (accessories not included)
- Pump mount location (pump mount not included)
- All frame sizes fit either 1 water bottle cage (not included) or a Fazua Energy range-extender battery (not included)
- Frame protection on down tube, main pivot, seatstay and chainstay
- Pedals not included
- NOTE: Specs and images are subject to change based on component availability
Imported.
- 1 year of free adjustments (see more below)
- In-store bike assembly
- Pickup in store or curbside
- Bike experts available at 170+ bike shops
- An additional year of free adjustments on e-bikes
- 20% off shop services
- Free tubes with purchase of flat tire repair (Co-op Cycles brand tubes only; tube must be installed at time of purchase)
New bikes go through a normal break-in period, after which they should be readjusted. All electric bicycles sold at REI include free adjustments for the defined period (one year after purchase date for non-members, or two years for REI Co-op Members)—as many times as you need. Included: derailleur and brake adjustments, lateral wheel truing, hub and headset bearing adjustments, tire inflation, chain lubrication and e-bike firmware updates. Not included: replacement or installation of new components or accessories, any other services. Call your local REI Co-op Bike Shop for more information.
UL2849 certified
| Best Use | Mountain Biking |
|---|---|
| E-Bike Classification | Class 1: pedal assist up to 20 mph |
| Motor | Fazua Ride 60 |
| Motor Type | Mid-Drive |
| Motor Torque (Nm) | 60 Newton meters |
| Battery Type | Lithium Ion |
| Battery Capacity (Wh) | 430 watt hours |
| Battery Removable | No |
| Charge Time (hrs) | 3.5 hours |
| Mountain Bike Style | Trail |
| Frame | 6061-T6 aluminum alloy |
| Bike Suspension | Full Suspension |
| Fork | Rockshox Psylo Silver RC, 160 mm |
| Fork Travel | 160 millimeters |
| Rear Shock | Rock Shox Deluxe Select |
| Crankset | FSA CK-730 Fazua Ride 60 crank arms, 55 mm CL, 104 BCD Spider, MegaTooth 34T steel chainring |
| Bottom Bracket | Integrated with Fazua motor |
| Shifters | Shimano CUES U6000 |
| Rear Derailleur | Shimano CUES U6000 Shadow Plus |
| Rear Cogs | Shimano LG400, 11-48T, 10-speed |
| Number of Gears | 10 gear(s) |
| Brake Type | Hydraulic Disc Brake |
| Brakes | Shimano MT420 |
| Brake Levers | Shimano M4100 |
| Rims | WTB ST i30 Tough TCS, 32h |
| Front Hub | Shimano TC500-15-B CLD |
| Rear Hub | Shimano TC500-MS-B CLD |
| Wheel Size | 29 inches |
| Tires | Front: Teravail Kessel 29 x 2.6 in., Rear: Teravail Warwick 29 x 2.5 in., Durable casing (WTB TCS sealant included) |
| Tire Width | 2.6 inches 2.5 inches |
| Handlebar Shape | Flat Bar |
| Handlebar | Race Face Chester 35.0 mm, 20 mm rise, 780 mm wide |
| Stem | Salsa 35.0 Guide Trail, 40 mm |
| Seat Post | Tranz X YSP18; SM/MD: 150 mm travel; LG/XL: 170 mm travel |
| Dropper Post | Yes |
| Saddle | WTB Solano, medium, Fusion Form, steel rail |
| Pedals | Not included |
| Headset | FSA Orbit 1.5E ZS NO.57E |
| Chain | Shimano LG500 |
| Weight | Unavailable |
| Gender | Unisex |
| S | M | L | XL | |
|---|---|---|---|---|
| Height Range | 5'2" - 5'7" | 5'6" - 5'11" | 5'10" - 6'3" | 6'2" and up |
| Reach | 453 | 473 | 493 | 513 |
| Stack | 613.6 | 622.6 | 631.6 | 640.5 |
| Effective Top Tube | 590.2 | 612.2 | 634.2 | 656.2 |
| Seat Tube Center-Top | 405 | 430 | 455 | 480 |
| Standover Height | 754.6 | 754.5 | 754.3 | 754.2 |
| Head Tube Length | 100 | 110 | 120 | 130 |
| Head Tube Angle (degrees) | 63.9 | 63.9 | 63.9 | 63.9 |
| Seat Tube Angle (degrees) | 77.4 | 77.4 | 77.4 | 77.4 |
| Bottom Bracket Height | 351 | 351 | 351 | 351 |
| Wheelbase | 1225 | 1249.4 | 1273.8 | 1298.2 |
| Chainstay | 435.3 | 435.3 | 435.3 | 435.3 |
| Fork Offset | 44 | 44 | 44 | 44 |
Sizing Notes
Measurements are stated in millimeters unless otherwise indicated.
How we measure bikes
- Standover Height Standover Height is a measurement from the ground to the top of the top tube, measured at the midpoint of the top tube.
- Reach Reach is the horizontal distance from the center of the cranks to the center of the head tube, measured at head tube level.
- Stack Stack is the vertical distance from the center of the cranks to the center of the head tube, measured to the top of the head tube.
- Effective Top Tube Effective top tube is the distance from the center of the head tube to the center of the seat tube/seat post, measured parallel to the ground.
- Seat Tube Center to Top Seat Tube length is the measurement of the seat tube, from the center of the cranks to the top of the seat tube.
- Head Tube Length Head Tube Length is measured from the bottom to the top of the head tube.
- Head Tube Angle Head Tube Angle is the acute angle between the head tube and the ground (measured towards the rear of the bike)
- Seat Tube Angle Seat Tube Angle is the acute angle between the seat tube and the ground (measured towards the rear of the bike).
- Bottom Bracket Height Bottom Bracket Height is a measurement taken vertically from the ground up to the center of the cranks.
- Wheelbase Wheelbase is the measurement from the center of the front axle to the center of the rear axle.
- Chainstay Length Chainstay Length is the measurement from the center of the cranks to the center of the rear axle.
- Fork Offset Fork Offset, or rake, is the distance from the front axle to a line drawn parallel to the center of the head tube or steering axis.
