Swift, versatile and fun, the Cannondale Quick Disc 3 bike lets you cruise through the city or get in a speedy, dynamic workout while feeling good on the lightweight aluminum frame with carbon fork.
- Lightweight SmartForm C3 alloy frame and carbon fiber fork offer a lightweight feel for improved control and handling
- Bump-absorbing SAVE micro-suspension, pressure-relieving saddle and a more upright forward riding position provide all-around comfort
- 2 x 9-speed shifting and responsive hydraulic disc brakes keep you in control going up hills or down
- OutFront steering geometry makes riding easier and more agile with the wheel positioned farther out in front for increased stability and control
- To blend speed with comfort, the Quick road-bike style wheels are fitted with larger volume tires for extra bump absorption, grip and durability
- Integrated wheel sensor delivers hyperaccurate speed, route and distance info, bike registration, service reminders and more via the free Cannondale app
- Intellimount stem mount secures any SP-Connect compatible smartphone case to view the app's dashboard display stats (phone case not included)
- StraightShot internal cable routing makes for clean lines and easy maintenance
- Fender brackets and universal rack mounts let you customize the Quick 3 for riding in foul weather or making trips to the store (fenders and racks not included)
- Bright 360° reflective elements help to make you more visible to motorists in low light
- NOTE: Specs and images are subject to change based on component availability
Imported.
- 1 year of free adjustments (see more below)
- In-store bike assembly
- Pickup in store or curbside
- Bike experts available at 170+ bike shops
- 20% off shop services
- Free tubes with purchase of flat tire repair (Co-op Cycles brand tubes only; tube must be installed at time of purchase)
New bikes go through a normal break-in period, after which they should be readjusted. All bicycles sold at REI include free adjustments for one year after purchase date—as many times as you need. Included: derailleur and brake adjustments, lateral wheel truing, hub and headset bearing adjustments, tire inflation and chain lubrication. Not included: replacement or installation of new components or accessories, any other services. Call your local REI Co-op Bike Shop for more information.
| Best Use | Recreational Cycling |
|---|---|
| Frame | SmartForm C3 Alloy, SAVE, tapered head tube, Straightshot hidden cable routing, flat mount disc, rack/fender mounts, 360 deg. reflectivity |
| Bike Suspension | No Suspension |
| Fork | Full carbon, 12 x 100 mm thru axle, 1-1/4 to 1-1/8 in. tapered steerer, flat mount disc, fender mounts, 360 deg. reflectivity |
| Crankset | Prowheel, 48/32T |
| Bottom Bracket | Cartridge, square taper |
| Shifters | 9-speed |
| Front Derailleur | Shimano Acera, 31.8 clamp |
| Rear Derailleur | Shimano Altus |
| Rear Cogs | 11-34T, 9-speed |
| Number of Gears | 18 gear(s) |
| Brake Type | Hydraulic Disc Brake |
| Brakes | Tektro HD-R280 hydro disc, 160/140 mm rotors |
| Brake Levers | Tektro HD-R280 hydraulic disc |
| Rims | Cannondale Disc, double-wall with eyelet, 32 h |
| Front Hub | Alloy, Sealed, 12 x 100 mm |
| Rear Hub | Alloy, Sealed QR |
| Wheel Size | 700c |
| Tires | Schwalbe Spicer, 700c x 35. mm, K-Guard, reflective strip |
| Tire Width | 35 millimeters |
| Handlebar Shape | Riser Bar |
| Handlebar | 6061 Alloy Double-butted, 25mm rise, 8 deg. sweep, 6 deg. rise, 640 mm |
| Stem | Cannondale 3 with Intellimount, alloy, 31.8 mm clamp |
| Seat Post | 6061 Alloy, 27.2 x 350 mm |
| Saddle | Cannondale Fitness Ergo Double Density |
| Pedals | Cannondale Fitness Reinforced Composite |
| Headset | 1-1/4 - 1-1/8 in. |
| Chain | KMC Z9, 9-speed |
| Weight | 25 lbs. 6.4 oz. |
| Bike Weight | Bike weight is based on median size, as sold, or the average of two median sizes. |
| Gender | Unisex |
| S | M | L | XL | XXL | |
|---|---|---|---|---|---|
| Height Range | 5'2" - 5'7" | 5'5" - 5'10" | 5'9" - 6'2" | 6'0" - 6'5" | 6'4'' - 6'9'' |
| Reach | 39.8 | 40.6 | 41.4 | 42.2 | 43.0 |
| Stack | 55.4 | 57.8 | 60.2 | 62.6 | 65.0 |
| Effective Top Tube | 56.7 | 58.3 | 59.8 | 61.3 | 62.8 |
| Seat Tube Center-Top | 40.0 | 45.0 | 50.0 | 55.0 | 60.0 |
| Standover Height | 69.9 | 74.1 | 78.2 | 82.2 | 86.2 |
| Head Tube Length | 13.3 | 15.8 | 18.4 | 20.9 | 23.4 |
| Head Tube Angle (degrees) | 71.0° | 71.0° | 71.0° | 71.0° | 71.0 |
| Seat Tube Angle (degrees) | 73.0° | 73.0° | 73.0° | 73.0° | 73.0° |
| Bottom Bracket Height | 28.2 | 28.2 | 28.2 | 28.2 | 28.2 |
| Wheelbase | 105.3 | 106.9 | 108.6 | 110.2 | 111.8 |
| Chainstay | 43.5 | 43.5 | 43.5 | 43.5 | 43.5 |
| Fork Offset | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 |
Sizing Notes
Measurements are stated in centimeters unless otherwise indicated.
How we measure bikes
- Standover Height Standover Height is a measurement from the ground to the top of the top tube, measured at the midpoint of the top tube.
- Reach Reach is the horizontal distance from the center of the cranks to the center of the head tube, measured at head tube level.
- Stack Stack is the vertical distance from the center of the cranks to the center of the head tube, measured to the top of the head tube.
- Effective Top Tube Effective top tube is the distance from the center of the head tube to the center of the seat tube/seat post, measured parallel to the ground.
- Seat Tube Center to Top Seat Tube length is the measurement of the seat tube, from the center of the cranks to the top of the seat tube.
- Head Tube Length Head Tube Length is measured from the bottom to the top of the head tube.
- Head Tube Angle Head Tube Angle is the acute angle between the head tube and the ground (measured towards the rear of the bike)
- Seat Tube Angle Seat Tube Angle is the acute angle between the seat tube and the ground (measured towards the rear of the bike).
- Bottom Bracket Height Bottom Bracket Height is a measurement taken vertically from the ground up to the center of the cranks.
- Wheelbase Wheelbase is the measurement from the center of the front axle to the center of the rear axle.
- Chainstay Length Chainstay Length is the measurement from the center of the cranks to the center of the rear axle.
- Fork Offset Fork Offset, or rake, is the distance from the front axle to a line drawn parallel to the center of the head tube or steering axis.
