Take charge on the descents and singletracks with the Cannondale Trail 5 hardtail mountain bike. It's built with reliable 1x gearing, 100 mm of plush front suspension and a sturdy aluminum frame.
Wheel Size
XS: 27.5 inches
Fork Travel
100 millimeters
Number of Gears
10 gear(s)
- Durable SmartForm C3 alloy frame offers delivers an exceptionally lightweight, efficient and smooth ride
- SR Suntour XCM fork offers 100 mm of travel with smooth suspension
- SAVE micro-suspension offers a smoother, more controlled ride with strategically engineered flex zones built into the frame's rear triangle
- Slack 68° head angle creates exceptionally stable handling to charge the descents with confidence
- microSHIFT Advent X rear derailleur and shifter deliver smooth shifting through all 10 gears
- Reliable Shimano hydraulic disc brakes provide great stopping power and control
- WTB Ranger Comp wheels rip around every turn with steadfast grip
- StraightShot internal cable routing for shifting and dropper post cables in the down tube makes for clean lines and easy maintenance; rear brake line runs outside the frame
- Compatible with 31.6 mm dropper posts (not included)
- NOTE: Specs and images are subject to change based on component availability
Imported.
This bike comes with Coast to Coast Support, which includes:
New bikes go through a normal break-in period, after which they should be readjusted. All bicycles sold at REI include free adjustments for one year after purchase date—as many times as you need. Included: derailleur and brake adjustments, lateral wheel truing, hub and headset bearing adjustments, tire inflation and chain lubrication. Not included: replacement or installation of new components or accessories, any other services. Call your local REI Co-op Bike Shop for more information.
View the Cannondale Trail Product LineView all Cannondale Hardtail Mountain Bikes- 1 year of free adjustments (see more below)
- In-store bike assembly
- Pickup in store or curbside
- Bike experts available at 170+ bike shops
- 20% off shop services
- Free tubes with purchase of flat tire repair (Co-op Cycles brand tubes only; tube must be installed at time of purchase)
New bikes go through a normal break-in period, after which they should be readjusted. All bicycles sold at REI include free adjustments for one year after purchase date—as many times as you need. Included: derailleur and brake adjustments, lateral wheel truing, hub and headset bearing adjustments, tire inflation and chain lubrication. Not included: replacement or installation of new components or accessories, any other services. Call your local REI Co-op Bike Shop for more information.
| Best Use | Mountain Biking |
|---|---|
| Frame | SmartForm C3 alloy, 1-1/8 in. headtube, dropper post compatible |
| Mountain Bike Style | Trail |
| Bike Suspension | Front Suspension |
| Fork | SR Suntour XCM, 100 mm travel, coil, 42 mm offset (27.5 in.) 46 mm offset (29 in.) |
| Fork Travel | 100 millimeters |
| Crankset | Prowheel, Charm 30T |
| Bottom Bracket | Cartridge square taper |
| Shifters | microSHIFT Advent X, 10-speed |
| Rear Derailleur | microSHIFT Advent X |
| Rear Cogs | microSHIFT, 11-48T, 10-speed |
| Number of Gears | 10 gear(s) |
| Brake Type | Hydraulic Disc Brake |
| Brakes | Shimano MT200 hydraulic disc, 160/160 mm RT10 rotors |
| Brake Levers | Shimano MT200 hydraulic disc |
| Rims | WTB SX19, 32 h |
| Front Hub | Shimano HBTX 505 |
| Rear Hub | Shimano FHTX 505 |
| Wheel Size | XS: 27.5 inches |
| Tires | WTB Ranger Comp |
| Tire Width | 2.25 inches |
| Handlebar Shape | Riser Bar |
| Handlebar | 6061 alloy, 25mm rise, 8 deg. sweep, 6 deg. rise, 720 mm |
| Stem | 6061 alloy, 31.8, 7 deg. |
| Seat Post | 6061 alloy, 31.6 x 350 mm |
| Saddle | Cannondale Stage 3 |
| Pedals | Cannondale Platform |
| Headset | 1-1/8 in. |
| Chain | KMC X10, 10-speed |
| Weight | 32 lbs. 6.4 oz. |
| Bike Weight | Bike weight is based on median size, as sold, or the average of two median sizes. |
| Gender | Unisex |
Cannondale Bikes (184492)
| XS | S | M | L | XL | |
|---|---|---|---|---|---|
| Height Range | 5'1''-5'2'' | 5'1''-5'4'' | 5'4''-5'8'' | 5'7''-6'0'' | 6'0''-6'3'' |
| Reach | 36.5 | 40.2 | 42.5 | 44.7 | 46.9 |
| Stack | 57.3 | 59.1 | 62.3 | 63.2 | 64.1 |
| Effective Top Tube | 53.5 | 57.7 | 50.9 | 63.4 | 65.9 |
| Seat Tube Center-Top | 53.5 | 57.7 | 60.9 | 63.4 | 65.9 |
| Standover Height | 67.3 | 71 | 76.8 | 79.5 | 83.9 |
| Head Tube Length | 9.5 | 9.5 | 10.5 | 11.5 | 12.5 |
| Head Tube Angle (degrees) | 68 | 68 | 68 | 68 | 68 |
| Seat Tube Angle (degrees) | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 |
| Bottom Bracket Height | 29.3 | 29.3 | 30.7 | 30.7 | 30.7 |
| Wheelbase | 105.4 | 109.8 | 114 | 116.6 | 119.2 |
| Chainstay | 44 | 44 | 44.5 | 44.5 | 44.5 |
| Fork Offset | 4.2 | 4.2 | 4.6 | 4.6 | 4.6 |
Sizing Notes
Measurements are stated in centimeters unless otherwise indicated.
How we measure bikes
- Standover Height Standover Height is a measurement from the ground to the top of the top tube, measured at the midpoint of the top tube.
- Reach Reach is the horizontal distance from the center of the cranks to the center of the head tube, measured at head tube level.
- Stack Stack is the vertical distance from the center of the cranks to the center of the head tube, measured to the top of the head tube.
- Effective Top Tube Effective top tube is the distance from the center of the head tube to the center of the seat tube/seat post, measured parallel to the ground.
- Seat Tube Center to Top Seat Tube length is the measurement of the seat tube, from the center of the cranks to the top of the seat tube.
- Head Tube Length Head Tube Length is measured from the bottom to the top of the head tube.
- Head Tube Angle Head Tube Angle is the acute angle between the head tube and the ground (measured towards the rear of the bike)
- Seat Tube Angle Seat Tube Angle is the acute angle between the seat tube and the ground (measured towards the rear of the bike).
- Bottom Bracket Height Bottom Bracket Height is a measurement taken vertically from the ground up to the center of the cranks.
- Wheelbase Wheelbase is the measurement from the center of the front axle to the center of the rear axle.
- Chainstay Length Chainstay Length is the measurement from the center of the cranks to the center of the rear axle.
- Fork Offset Fork Offset, or rake, is the distance from the front axle to a line drawn parallel to the center of the head tube or steering axis.
