- Lightweight 4130 chromoly steel frame with tons of clearance and rack-mounting points make this bike a touring beast of burden
- Gravel-ready geometry and beefy 700c x 38mm Hutchinson Override tires keep you in control on loose surfaces
- Frame and fork are compatible with 650b wheels (not included) so you can roll even wider tires when you want to
- 16-speed Shimano Claris STI drivetrain delivers excellent gearing for adventure gravel rides or commuting
- 3-piece FSA Tempo Adventure compact double 48/32t crankset gives a wide range of gears to tackle gravel climbs and rough roads
- Wheels are built with tubeless-ready 700c WTB STP i23 32-hole rims with stainless-steel spokes and alloy hubs
- Promax DC-330R flat mount mechanical disc brakes provide stopping power even in wet conditions
- Adjustable drop handlebar with a variety of hand positions and gel-padded tape
- Selle Royal Rampage adventure saddle offers comfort on extended rides
- NOTE: Specs and images are subject to change based on component availability
Imported.
- 1 year of free adjustments (see more below)
- In-store bike assembly
- Pickup in store or curbside
- Bike experts available at 170+ bike shops
- 20% off shop services
- Free tubes with purchase of flat tire repair (Co-op Cycles brand tubes only; tube must be installed at time of purchase)
New bikes go through a normal break-in period, after which they should be readjusted. All bicycles sold at REI include free adjustments for one year after purchase date—as many times as you need. Included: derailleur and brake adjustments, lateral wheel truing, hub and headset bearing adjustments, tire inflation and chain lubrication. Not included: replacement or installation of new components or accessories, any other services. Call your local REI Co-op Bike Shop for more information.
Best Use | Bike Touring |
---|---|
Frame | Chromoly steel |
Fork | Chromoly steel |
Bike Suspension | No Suspension |
Crankset | FSA Tempo Adventure, 48/32t chainrings |
Bottom Bracket | FSA square taper, sealed cartridge |
Shifters | Shimano Claris |
Front Derailleur | Shimano Claris |
Rear Derailleur | Shimano Claris |
Rear Cogs | Sunrace CSM55 8spd 11-34t cassette |
Number of Gears | 16 gear(s) |
Brake Type | Mechanical Disc Brake |
Brakes | Promax DC-330R flat mount |
Brake Levers | Shimano Claris |
Rims | WTB STP i23 32-hole rims, stainless-steel spokes |
Front Hub | Alloy front disc hub |
Rear Hub | Alloy cassette rear disc hub |
Wheel Size | 700c |
Tires | Hutchinson Overide |
Tire Width | 38 millimeters |
Handlebar Shape | Drop Bar |
Handlebar | Pure Cycles alloy drop 31.8mm |
Stem | Pure Cycles alloy |
Seat Post | Alloy micro-adjust, 27.2 x 350mm |
Saddle | Selle Royal Rampage |
Pedals | VP alloy Test Ride |
Headset | 1-1/8 threadless |
Chain | KMC Z-8 |
Bike Weight | Bike weight is based on median size, as sold, or the average of two median sizes. |
Gender | Unisex |
S | M | L | XL | |
---|---|---|---|---|
Effective Top Tube | 550 | 560 | 565 | 582 |
Standover Height | 764 | 780 | 814 | 840 |
Head Tube Length | 120 | 130 | 155 | 170 |
Head Tube Angle (degrees) | 71 | 71.5 | 71.5 | 71.5 |
Seat Tube Angle (degrees) | 74 | 73.5 | 73 | 72.5 |
Bottom Bracket Height | 72 | 72 | 70 | 70 |
Wheelbase | 1060 | 1060 | 1061 | 1073 |
Chainstay | 455 | 455 | 455 | 455 |
Fork Offset | 50 | 50 | 50 | 50 |
Sizing Notes
Measurements are stated in millimeters unless otherwise stated.
How we measure bikes
- Standover Height Standover Height is a measurement from the ground to the top of the top tube, measured at the midpoint of the top tube.
- Reach Reach is the horizontal distance from the center of the cranks to the center of the head tube, measured at head tube level.
- Stack Stack is the vertical distance from the center of the cranks to the center of the head tube, measured to the top of the head tube.
- Effective Top Tube Effective top tube is the distance from the center of the head tube to the center of the seat tube/seat post, measured parallel to the ground.
- Seat Tube Center to Top Seat Tube length is the measurement of the seat tube, from the center of the cranks to the top of the seat tube.
- Head Tube Length Head Tube Length is measured from the bottom to the top of the head tube.
- Head Tube Angle Head Tube Angle is the acute angle between the head tube and the ground (measured towards the rear of the bike)
- Seat Tube Angle Seat Tube Angle is the acute angle between the seat tube and the ground (measured towards the rear of the bike).
- Bottom Bracket Height Bottom Bracket Height is a measurement taken vertically from the ground up to the center of the cranks.
- Wheelbase Wheelbase is the measurement from the center of the front axle to the center of the rear axle.
- Chainstay Length Chainstay Length is the measurement from the center of the cranks to the center of the rear axle.
- Fork Offset Fork Offset, or rake, is the distance from the front axle to a line drawn parallel to the center of the head tube or steering axis.
