The Co-op Cycles REV CTY 24 step-through kids' bike gives young riders an easy-to-straddle stand-over height, to help build confidence and skills for riding— from street to trail.
Wheel Size
24 inches
Number of Gears
21 gear(s)
- Aluminum frame is lightweight and durable
- Shimano drivetrain provides 21 versatile gearing options for hills, flats and rolling terrain
- Linear pull rim brakes provide responsive braking power
- All-terrain tires are mounted on sturdy rims for excellent performance on and off the road
- Please note: the small frame may not fit standard size bottle cages and water bottles; side entry cages are recommended (not included)
- Bicycle weight limit is 120 lbs. total, including rider + all gear carried on the bike and on the rider's body
- NOTE: Specs and images are subject to change based on component availability
Imported.
This bike comes with Coast to Coast Support, which includes:
New bikes go through a normal break-in period, after which they should be readjusted. All bicycles sold at REI include free adjustments for one year after purchase date—as many times as you need. Included: derailleur and brake adjustments, lateral wheel truing, hub and headset bearing adjustments, tire inflation and chain lubrication. Not included: replacement or installation of new components or accessories, any other services. Call your local REI Co-op Bike Shop for more information.
View the Co-op Cycles Rev Product LineView all Co-op Cycles Kids' Cruiser Bikes- 1 year of free adjustments (see more below)
- In-store bike assembly
- Pickup in store or curbside
- Bike experts available at 170+ bike shops
- 20% off shop services
- Free tubes with purchase of flat tire repair (Co-op Cycles brand tubes only; tube must be installed at time of purchase)
New bikes go through a normal break-in period, after which they should be readjusted. All bicycles sold at REI include free adjustments for one year after purchase date—as many times as you need. Included: derailleur and brake adjustments, lateral wheel truing, hub and headset bearing adjustments, tire inflation and chain lubrication. Not included: replacement or installation of new components or accessories, any other services. Call your local REI Co-op Bike Shop for more information.
| Best Use | Recreational Cycling |
|---|---|
| Frame | 6061 aluminum |
| Step-Through | Yes |
| Bike Suspension | No Suspension |
| Fork | 6061 aluminum |
| Crankset | Alloy, 42/34/24 |
| Bottom Bracket | Cartridge |
| Shifters | Shimano Tourney |
| Front Derailleur | Shimano Tourney |
| Rear Derailleur | Shimano Tourney |
| Rear Cogs | Shimano Tourney, 14-34, 7-speed |
| Number of Gears | 21 gear(s) |
| Brake Type | Rim |
| Brakes | Logan linear pull |
| Rims | Aluminum |
| Front Hub | Joytech, with nutted axle |
| Rear Hub | Joytech, with nutted axle |
| Wheel Size | 24 inches |
| Tires | Kenda Cosmos, 24" x 1.5" |
| Tire Width | 1.5 inches |
| Handlebar Shape | Riser Bar |
| Handlebar | Steel riser |
| Stem | Alloy |
| Seat Post | Alloy |
| Saddle | Co-op Cycles |
| Pedals | Wellgo composite platform |
| Headset | Semi cartridge |
| Chain | KMC Z51 |
| Bike Weight | Bike weight is based on median size, as sold, or the average of two median sizes. |
| Gender | Kids' |
| Sustainability | From a Climate Neutral Certified brand |
Co-op Cycles Bikes (143202)
| 24 IN | |
|---|---|
| Reach | 366.3 |
| Stack | 439.4 |
| Effective Top Tube | 500.58 |
| Seat Tube Center-Top | 320 |
| Standover Height | 579.2 |
| Head Tube Angle (degrees) | 71 |
| Seat Tube Angle (degrees) | 73 |
| Wheelbase | 943.65 |
| Chainstay | 390 |
| Fork Offset | 45 |
Sizing Notes
Measurements are stated in millimeters unless otherwise indicated.
How we measure bikes
- Standover Height Standover Height is a measurement from the ground to the top of the top tube, measured at the midpoint of the top tube.
- Reach Reach is the horizontal distance from the center of the cranks to the center of the head tube, measured at head tube level.
- Stack Stack is the vertical distance from the center of the cranks to the center of the head tube, measured to the top of the head tube.
- Effective Top Tube Effective top tube is the distance from the center of the head tube to the center of the seat tube/seat post, measured parallel to the ground.
- Seat Tube Center to Top Seat Tube length is the measurement of the seat tube, from the center of the cranks to the top of the seat tube.
- Head Tube Length Head Tube Length is measured from the bottom to the top of the head tube.
- Head Tube Angle Head Tube Angle is the acute angle between the head tube and the ground (measured towards the rear of the bike)
- Seat Tube Angle Seat Tube Angle is the acute angle between the seat tube and the ground (measured towards the rear of the bike).
- Bottom Bracket Height Bottom Bracket Height is a measurement taken vertically from the ground up to the center of the cranks.
- Wheelbase Wheelbase is the measurement from the center of the front axle to the center of the rear axle.
- Chainstay Length Chainstay Length is the measurement from the center of the cranks to the center of the rear axle.
- Fork Offset Fork Offset, or rake, is the distance from the front axle to a line drawn parallel to the center of the head tube or steering axis.
